Heavy Oil Burners


TECHNOPRESS

[kW 105 ÷ 1900]
PN30 PN60 PN70 PN81

Thanks to CIB UNIGAS’s fourty years experience in the design and production of oiI burners, we produce a highly technical series of products renowned worldwide for their reliability. These burners, in the standard version, are available to burn oil with viscosity up to 110 cSt at 50° C (15°E at 50°C). Upon request we can also supply a model for heavy oil up to 400 cSt at 50°C (50°Eat 50°C). The oil heater consists of a tank equipped with an electric element, while a system of preset thermostats controls the regulation of the fuel temperature in order to ensure the optimum performance of the fuel used. Upon request we can supply the components necessary to ensure that the oil supply line complies with UNI 9248.

Technical Data PN70


Additional charges for petroleum, waste oil and other types of oils: quote on request

Type Model Power min. Power max. Power supply Motor Fan
PN70 N-.AB.S.XX.A 291 kW 1047 kW 230/400 V 3N AC 2,20 kW
PN70 N-.PR.S.XX.A 291 kW 1047 kW 230/400 V 3N AC 2,20 kW
PN70 N-.MD.S.XX.A 291 kW 1047 kW 230/400 V 3N AC 2,20 kW
PN70 N-.PR.S.XX.A.EA 291 kW 1047 kW 230/400 V 3N AC 2,20 kW
PN70 N-.MD.S.XX.A.ES 291 kW 1047 kW 230/400 V 3N AC 2,20 kW

NOTE: The above models differ in the type of ramp connection, regulation and type of control (mechanical/electronic). If in doubt, contact our sales offices.

Technical Data PN81


Additional charges for petroleum, waste oil and other types of oils: quote on request

Type Model Power min. Power max. Power supply Motor Fan
PN81 N-.AB.S.XX.A 264 kW 1900 kW 230/400 V 3N AC 3 kW
PN81 N-.PR.S.XX.A 264 kW 1900 kW 230/400 V 3N AC 3 kW
PN81 N-.PR.S.XX.A.EA 264 kW 1900 kW 230/400 V 3N AC 3 kW
PN81 N-.MD.S.XX.A.ES 264 kW 1900 kW 230/400 V 3N AC 3 kW

NOTE: The above models differ in the type of ramp connection, regulation and type of control (mechanical/electronic). If in doubt, contact our sales offices.
