As An Oraganization We provide High Quality Gas Trains

2 Zone Output & Individual Zone Gas Train

Product Detail :

Brand/MakeGreen Line
QualityExcellent

Specification:

  • Primary and Secondary (Zone) pressure reduction in the single gas train.
  • 1 nos. main inlet and 2 nos. an outlet for separate zones.
  • Pressure Regulator and Pressure switch for individual zones.
  • Isolation ball valve for individual zone isolation and maintenance on a       gas train.
  • Common gas metering orifices in the main line.
  • CPI Switches for all solenoid valves to ensure positive valve closing       feedback.
  • Cost and space of the design.
  • Solenoid valves for individual zones in addition to main line solenoid       valves.
  • Pressure gauges with DPT valves at inlet and outlet gauge at each stage

Customized Gas Train With In Built Pilot Line

Product Detail :

Maximum Inlet Pressure2 bar
Max. Gas Flow 100Nm3/hr
Mounting MS structural Mounting skid

We deal in Customized Gas Train With In Built Pilot Line.

Straight Design Prepiped Gas Trains

Product Detail :

Sizes DN15 to DN200
Clamping Tube Clamps
Mounting MS structural Mounting skid

We manufacture Standard Straight Design Prepiped Gas Trains at our Pune (India) factory which are offered as a standalone product to the user.

These are most suitable in applications where the installtion space is limited in length and where the no of Safety and Control Instuments on the Gas Train are more.

Specification:

  • Gas Train type : Single/Multiple Burner
  • Service: LPG/Natural Gas/ Propane / If other specify Gas Composition
  • Inlet Gas Pressure : 1, 2 or 5 Bar (Higher Inlet request)
  • Piping : MS SCH40 Seamless Piping
  • Prewired junction Boxes provided on request
  • End Connections: Flanged as per ANSI B 16.5, 150

Ordering Information :

  • Gas to be used
  • Pipeline size
  • Max Inlet Pressure (bar)
  • Outlet Pressure range (mBar)
  • Max. Gas flow (Nm3/hr)
  • Power Supply/Control Voltage : (V ac/ V dc)
  • No. of Burners: Single/Multiple.

Loop Design Prepiped Gas Trains

Product Detail :

Sizes DN15 to DN100 (Higher Sizes on request)
Mounting MS structural Mounting skid
Gas Train type Single/Multiple Burner

Green Line Energy manufactures customized Loop Design Prepiped Gas Trains after careful study and analysis of the requirements of the combustion process at the customer's plant. These Trains are manufactured as per the guidelines and stringent standards of safety laid down by European and North American countries.

Specification:

  • Service: LPG/Natural Gas/ Propane / If other specify Gas Composition
  • Inlet Gas Pressure : Upto 5 Bar (Higher Inlet request)
  • Piping: MS SH40 Seamless ( Other piping on request)
  • Flow Measurement : Optional On Request
  • Prewired junction Boxes provided on request
